| Parameter | Detail |
| Motor Type | Brushless, fully sealed |
| Speed Range | 0-1250 RPM (±15%) |
| Output Torque | ≥3.8 N/M |
| Power Output | ≥160W |
| Noise Level | ≤55 dB |
| Temperature Rise | ≤25℃ |
| Weight | 665g |
| Chuck Diameter | 0-4mm (customizable) |
| Hollow Shaft Diameter | 0-2.6mm |
| Battery | Sony 8V 2600mAh lithium |
| Charging Time | 60 minutes (full charge) |
| Radial Runout | <0.1mm |
| Sterilization | Autoclavable at 134°C (excl. battery) |
| Warranty | 18 months (tool), 6 months (battery) |
| Certifications | ISO 13485, FDA, CE |
Ultra-Precise Brushless Motor Technology
Optimized for Minimally Invasive Surgery
Premium Engineering & Materials
The brushless motor features a fully enclosed, maintenance-free design with a hard-oxidized aluminum housing for superior corrosion resistance. The medical-grade stainless steel chuck (HRC53-hardened) supports 0-4mm drill bits, and smart thermal management prevents overheating during prolonged surgical use.
Surgical Applications
The brushless motor provides over 50,000 hours of maintenance-free operation, consistent torque, and eliminates carbon brush debris, making it ideal for sterile medical environments.
Yes, the handpiece is designed to be fully autoclavable at temperatures up to 134°C for strict infection control. Note that the battery must be removed before sterilization.
The drill uses a high-quality Sony 8V 2600mAh lithium battery that can be fully charged in just 60 minutes, ensuring minimal downtime between procedures.
The 0-2.6mm hollow shaft allows for the use of guide wires, which is critical for achieving precise alignment in complex procedures like spinal fusions or micro-fracture repairs.
Operating at ≤55 dB, the drill is quieter than a standard conversation. This reduces ambient noise in the operating room, improving focus for the surgical team and comfort for the patient.
The device is fully compliant with global medical standards, holding ISO 13485, FDA, and CE certifications, ensuring safety and quality for international use.
